Remtron™ 611
Industrial Remote Control
The Remtron™ 611 industrial remote control system has an operator control unit with six single-step motions plus start and stop functions. It is used for crane remote control, conveying systems, on and off-highway mobile equipment, manufacturing, transportation and warehousing.
HIGHLIGHTS
- Diagnostic data collection
- Customizable switch layout
- Closed box wireless configuration
- RFID security and rapid configuration
- PL-d safety level
- Global licensed and unlicensed frequencies
- Works with the 10R/17R MCU and CattronLink™
Long-Life Switches
Switches are measured in millions of cycles
IP65 Enclosure
Offers protection against harsh environments
Battery Life
Lasts beyond 65 hours with typical use; uses AA standard alkaline batteries
Enhanced Status Indicators
Include multiple LEDs and haptic feedback for simple and rapid deployment of spares
Closed Box Configuration
Wireless configuration of frequency and function enables simple and rapid deployment of spares
RFID Security and Rapid Configuration
Allocate user ID security and "as needed" reconfiguration of the operator control unit to a specific machine
PL-d Safety Level
Based on black channel telegram and redundant dual-processor architecture
Switch Layout
Customizable switch layout to meet application-specific requirements and white label programs
Diagnostic Data Collection
Data and diagnostics are logged and available over Bluetooth or SD Card
Global Frequencies
Frequency support in the 915 MHz, 868 MHz, 433 MHz and 2.4 GHz (unlicensed) and 450-470 MHz (licensed) spectrums
Ergonomic Switches
Feature an intuitive, tactile feel that makes it easy to differentiate among steps even while wearing gloves
Operating Range
Sub-GHz - 150 meters typical (500 ft)
2.4GHz - 180 meters typical (600 ft)
Illuminated Stop Switch
PL-d rated illuminated stop switch on every operator control unit
Rechargeable Battery
Optional rechargeable battery and charger
Warranty
Standard one-year product warranty
ISO Certification
Manufactured in an ISO 9001:2015 certified operation
Hoist/Crane Select
Includes indications shown on four status LEDs
White Label Customization
Ability to customize the label of the OCU to include your brand or specific application identity
Crane Remote Control
Metals Manufacturing, Paper Mills, Fabrication, Maintenance
Conveyor Systems
Parcel Unloading, Parcel Movement, Assembly Line, Ship Loaders
On-Highway Mobile Equipment
Vacuum Trucks, Loader Cranes, Specialty Trucks, Concrete Pumps, Pressure Washing Trucks
Off-Highway Mobile Equipment
Light Towers, Fire Pumps, Generators, Dewatering Pumps, Terrain Cranes, Crawler Cranes, Rock Breakers, Screen Machines
Manufacturing
Robotics, Automated Conveying Systems
Transportation & Warehousing
Logistics, Distribution Centers, Robotics
Battery board
900224-E
PCA, BATTERY ~
Battery Door
570112-D
BATTERY COVER,T18A,T14A,T10A
Carrying strap
42C-0057
CARRY STRAP,PADDED SHOULDER STYLE,2 CLIPS,TOGGLE XMTR
Enclosure
3BOX-8995-A001
ENCLOSURE, BOTTOM, 14/18 SWITCH FUNCTION, PA66 GF, BLACK, REMTRON
Enclosure
3BOX-8995-A002
ENCLOSURE, TOP, 14/18 SWITCH FUNCTION, PA66 GF, BLACK, REMTRON
Enclosure
3BOX-8997-A001
ENCL,BOTTOM,10 SW. FUNCTION,PA66 GF,BLK*
Enclosure
3BOX-8995-A001
ENCLOSURE, BOTTOM, 14/18 SWITCH FUNCTION, PA66 GF, BLACK, REMTRON
Enclosure
3BOX-8995-A002
ENCLOSURE, TOP, 14/18 SWITCH FUNCTION, PA66 GF, BLACK, REMTRON
Enclosure
3BOX-8997-A001
ENCL,BOTTOM,10 SW. FUNCTION,PA66 GF,BLK*
Enclosure
3BOX-8997-A002
ENCL,TOP,10 SW. FUNCTION,PA66 GF,BLK*
Enclosure
3BOX-8997-A002
ENCL,TOP,10 SW. FUNCTION,PA66 GF,BLK*
Gasket
3GSK-8995-A101
GASKET, MAIN BODY SEAL, SILICONE, 55 SHORE A, 14/18 SWITCH FUNCTION, BLACK, REMTRON
Gasket
3GSK-8997-A101
GASKET,MAIN BODY SEAL,10 SW FUNCTION*
Holster
PRT-0002129
HOLSTER, LEATHER, FOR 14 & 18 SWITCH FUNCTION CONTROLLERS
Holster
PRT-0002130
HOLSTER, LEATHER, FOR 10 SWITCH FUNCTION CONTROLLERS
Label
3LBL-9000-A101
MEMBRANE, 10 SWITCH FUNCTION, REMTRON 411
Label
3LBL-9000-A201
MEMBRANE, 10 SWITCH FUNCTION, REMTRON, SAFE-D-STOP
Label
3LBL-9001-A101
MEMBRANE, 14 SWITCH FUNCTION, REMTRON 611
Label
3LBL-9001-A201
MEMBRANE, 18 SWITCH FUNCTION, REMTRON 325
Label
3LBL-9003-A001
LABEL, OVERLAY, POLYESTER, CRACKLE DESIGN, LOGO, REMTRON 411
Label
3LBL-9003-A011
LABEL,OVERLAY,SAFE-D,LOGO,CRACKLE
Label
3LBL-9004-A001
LABEL, OVERLAY, POLYESTER, CRACKLE DESIGN, LOGO, REMTRON 325
Label
3LBL-9004-A002
LABEL, OVERLAY, POLYESTER, CRACKLE DESIGN, LOGO, REMTRON 611
Label
3LBL-9005-A001
LABEL, OVERLAY, POLYESTER, INSERTS, SHEET, REMTRON
Label
3LBL-9005-A011
LABEL,OVERLAY,INSERT SHEET,POLYESTER
Oing ring
530208-B
O-RING,NEOPRENE #224
Screw
SCR-0000262
SCREW,SELF-SEAL,6-32X.70,INCLUDES *
Screw
SCR-0000264
SCREW,MACH,PH,PHIL,M2.5-0.45X5MM LG,EXT*
