In an emergency, every second counts. Air-Eagle Wireless E-Stops by BWI Eagle enable workers to intervene and take immediate action, especially when a fixed e-stop is out of reach. The lightweight wireless e-stop can be carried, worn on a belt or mounted in a vehicle to provide instant access all day from anywhere within range.
The transmitter and receiver are in constant two-way communication and programmed to send a periodic heartbeat signal between the transmitter and receiver to monitor the connection continuously. As long as the signal between the units remains linked, the receiver keeps one or more relays energized and the machinery running. The linked relays de-energize immediately upon activation of the wireless e-stop button. In the event of link loss between the transmitter and receiver, the linked relays de-energize after a specified timeout period, preventing the machinery from running unprotected.
- Operating ranges from 600 to 5,000 feet
- Can be hard-wired into any standard e-stop circuit
- USB rechargeable lithium-ion battery
- IEC 61508/SIL Safety Verified
- Eight independent network frequencies
- Continuous two-way monitoring
- Proudly manufactured in the USA
-
Configuration Sheets
Frequency
Varies by model
- 900 MHz spread spectrum
- 2.4 GHz spread spectrum
Buttons
Transmitter models with four buttons plus an emergency stop
Keypad
The durable sealed membrane keypad eliminates dust, dirt and moisture failures and features an LED display for feedback
Fail-Safe Monitoring
Heartbeat signal provides continuous two-way monitoring between the transmitter and receiver to ensure your stop command will always be heard
RF Networks
Eight independent network frequencies
Operating Range
Varies by model
- Up to 600, 2,500 or 5,000 feet
Battery Type
Internally sealed lithium rechargeable battery
RF Power
Varies by model
- 60mW
- 250 mW, 125mW, 75mW
- 1W, 500mW, 100mW
Operating Temperature
-40° F to +185° F (-40° C to +85° C)
Housing & Protection
Varies by model
- IP40-rated, ABS plastic and aluminum enclosure
- IP66-rated, (NEMA 4) polycarb enclosure
Belt Clip
Comes standard with an aluminum belt clip
Mounting Plate
For mounting in a vehicle, forklift or in any permanent location
